Pancake Cylinder - PC D050

You are here : All products > Clamping Elements > Pancake Cylinder > Pancake Cylinder - PC D050

Information

Pancake pneumatic cylinders has been designed to satisfy the needs of short-stroke applications. These are compact air cylinders that can fit into small space. The Pancake cylinders have combination of features, options, quality, strength, appearance and long life.


Models available - D012, D020, D030, D060, D080 and D100.


MRP : 500/- + (GST 18% Extra)

Offer price : 400/- + (GST 18% Extra)

Ordering code : PC D050 0100

Available stock : 10

MOQ : 2 (Nos.)

Delivery days : 7

Share product - Pancake Cylinder - PC D050

Technical specifications

Finish Weight in Kg 1.4
Overall Dimns. in mm 60 x 60 x 70
Clamping force 100 Kg
Operating Stroke 5 mm
Operating pressure 6 Bars

Working principle

Pancake cylinders are compact cylinders, uses standard 12.9 grade bolts and aluminum spacers to lock precision machined flanges tightly around a high strength cylinder body, cylinder is highly smooth machined for long life with specialized seals. Designed for high impacts. Uses non-Metallic bearings for smooth functioning.

These cylinders are available in various sizes, and defined with piston diameter i.e. D050 = Piston diameter = 50 mm.

For your specific requirement contact us at - sales@prsverse.com


Product features

Hydraulic actuation

Double acting return hydraulic force.

Single acting return with spring force.

Robust all steel construction.

Parts are hardened for performance.

Blackodised to avoid rusting.


Material of construction

Components are manufactured from Alloy Steel

Components are Manufactured from Rolled bars.

Components are treated for rust prevention.

Components are Treated for wear and Strength.

Raw materials from indigenous source only.

All bought out Items from reputed manufacturers.


Applications

CNC Machines Fixtures

Pneumatic Press Dies.

Forging Press Dies.

Moulding dies and Fixtures

General purpose clamping.
