QL Vise - W 80 x 130

You are here : All products > Production Systems > Quic Lock - Vise > QL Vise - W 80 x 130

Information

This revolutionary 'Quick 5 Axis Vise Lock' technology allows to fix, position and clamp in a single step, cutting set time by reduced up to 90%. Available with single point mechanical release, these positive locking and locating modules allow operators to quickly change out large and small fixtures with extreme accuracy and minimum effort.


Supplied with 4 types of Jaw set of 2 each - Dovetail, Serrated, Vertical - V and Horizontal - V

MRP : 10964/- + (GST 18% Extra)

Offer price : 10500/- + (GST 18% Extra)

Ordering code : QL W080 0100

Available stock : 5

MOQ : 1 (Nos.)

Delivery days : 20

Share product - QL Vise - W 80 x 130

More varients of Quic Lock - Vise

Technical specifications

Working principle

This is a mechanical clamping units utilize mechanical leverage, such as screws, levers, or cams, to apply force. These are typically simpler and more cost-effective than hydraulic or pneumatic systems but require manual or semi-automated operation. Mechanical systems apply clamping force through physical mechanisms, often requiring manual adjustment or tightening.

Product features

No external power source is required.

Cost-effective and suitable for small-scale operations.

Simple to operate and maintain.

Material of construction

Components are manufactured from Alloy Steel

Components are Manufactured from Rolled bars.

Components are treated for rust prevention.

Components are Treated for wear and Strength.

Raw materials from indigenous source only.

All bought out Items from reputed manufacturers.

Applications

Assembly lines, light-duty machining, packaging, and robotic systems.

CNC Machines

Injection Moulding

EDM Machines

Welding Fixtures
